HTTP/2-based gRPC client (h2c cleartext, or TLS with ALPN "h2"). More...

#include <cwist/net/grpc/grpc_client.h>
#include <cwist/core/mem/alloc.h>
#include <arpa/inet.h>
#include <errno.h>
#include <fcntl.h>
#include <netdb.h>
#include <poll.h>
#include <pthread.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <strings.h>
#include <sys/socket.h>
#include <time.h>
#include <unistd.h>
#include <openssl/ssl.h>

Include dependency graph for grpc_client.c:

Go to the source code of this file.

Macros
#define	_POSIX_C_SOURCE 200809L

#define	GRPC_CLIENT_FRAME_HEADER 9

#define	GRPC_CLIENT_MAX_FRAME (16u * 1024u * 1024u)

#define	GRPC_CLIENT_DEFAULT_WINDOW 65535

#define	GRPC_CLIENT_HEADER_TABLE 4096

#define	H2_FRAME_DATA 0x00

#define	H2_FRAME_HEADERS 0x01

#define	H2_FRAME_RST_STREAM 0x03

#define	H2_FRAME_SETTINGS 0x04

#define	H2_FRAME_PUSH_PROMISE 0x05

#define	H2_FRAME_PING 0x06

#define	H2_FRAME_GOAWAY 0x07

#define	H2_FRAME_WINDOW_UPDATE 0x08

#define	H2_FRAME_CONTINUATION 0x09

#define	H2_FLAG_END_STREAM 0x01

#define	H2_FLAG_END_HEADERS 0x04

#define	H2_FLAG_ACK 0x01

Typedefs
typedef struct grpc_client_hpack_entry	grpc_client_hpack_entry

typedef struct grpc_client_msg	grpc_client_msg

typedef struct grpc_client_frame	grpc_client_frame

typedef void(*	grpc_client_header_cb) (void ctx, const char name, const char *value)

typedef struct grpc_client_headers_ctx	grpc_client_headers_ctx

Functions
cwist_grpc_client *	cwist_grpc_client_connect (const char host, uint16_t port, const cwist_grpc_client_options options)
	Connect to a gRPC server and complete the HTTP/2 handshake.

void	cwist_grpc_client_close (cwist_grpc_client *c)
	Close the client: send GOAWAY, tear down TLS and the socket, free all state.

cwist_grpc_call *	cwist_grpc_call_start (cwist_grpc_client c, const char method, const void *request, size_t request_len, uint64_t timeout_ms)
	Start a unary call (no previous-attempt marker).

cwist_grpc_call *	cwist_grpc_call_start_ex (cwist_grpc_client c, const char method, const void *request, size_t request_len, uint64_t timeout_ms, uint32_t previous_attempts)
	Start a unary call, with a gRFC A6 retry-attempt marker.

int	cwist_grpc_call_recv (cwist_grpc_call call, cwist_grpc_message out)
	Receive the next response message of a call.

int	cwist_grpc_call_await_headers (cwist_grpc_call *call)
	Block until response headers arrive or the stream ends.

int	cwist_grpc_call_committed (const cwist_grpc_call *call)
	Whether response headers have committed the RPC (gRFC A6).

int	cwist_grpc_call_refused (const cwist_grpc_call *call)
	Whether the call failed before commit in a retryable way (gRFC A6 case 3: REFUSED_STREAM before headers, or GOAWAY below our stream id).

int	cwist_grpc_call_retry_pushback_ms (const cwist_grpc_call call, int32_t out_ms)
	Report the server-provided retry pushback delay, if any.

int	cwist_grpc_client_dead (cwist_grpc_client *c)
	Whether the client connection is unusable.

cwist_grpc_status_t	cwist_grpc_call_status (const cwist_grpc_call *call)
	Current gRPC status code of a call.

cwist_grpc_status_t	cwist_grpc_call_finish (cwist_grpc_call call, const char *message)
	Drain the call to completion and return its final status.

void	cwist_grpc_call_cancel (cwist_grpc_call *call)
	Cancel a call: send RST_STREAM(CANCEL), mark it failed with CWIST_GRPC_CANCELLED, and end its stream.

void	cwist_grpc_call_destroy (cwist_grpc_call *call)
	Destroy a call: cancel it if still open, release it as the client's active call, and free all queued and buffered state.

Detailed Description

HTTP/2-based gRPC client (h2c cleartext, or TLS with ALPN "h2").

The client speaks a minimal but complete HTTP/2 subset: client preface, SETTINGS exchange, HEADERS/DATA framing with HPACK (encoding reuses the shared h2_encode_* helpers from net/http/http2.c; decoding keeps a small per-connection dynamic table), coarse flow control (WINDOW_UPDATE in both directions), PING ACKs, and GOAWAY tolerance. gRPC message framing reuses cwist_grpc_encode_message / cwist_grpc_decoder from grpc.c.

One active call per connection; the mutex serializes call setup.

Definition in file grpc_client.c.

Macro Definition Documentation

◆ _POSIX_C_SOURCE

#define _POSIX_C_SOURCE 200809L

Definition at line 15 of file grpc_client.c.

◆ GRPC_CLIENT_DEFAULT_WINDOW

#define GRPC_CLIENT_DEFAULT_WINDOW 65535

Definition at line 35 of file grpc_client.c.

◆ GRPC_CLIENT_FRAME_HEADER

#define GRPC_CLIENT_FRAME_HEADER 9

Definition at line 33 of file grpc_client.c.

◆ GRPC_CLIENT_HEADER_TABLE

#define GRPC_CLIENT_HEADER_TABLE 4096

Definition at line 36 of file grpc_client.c.

◆ GRPC_CLIENT_MAX_FRAME

#define GRPC_CLIENT_MAX_FRAME (16u * 1024u * 1024u)

Definition at line 34 of file grpc_client.c.

◆ H2_FLAG_ACK

#define H2_FLAG_ACK 0x01

Definition at line 49 of file grpc_client.c.

◆ H2_FLAG_END_HEADERS

#define H2_FLAG_END_HEADERS 0x04

Definition at line 48 of file grpc_client.c.

◆ H2_FLAG_END_STREAM

#define H2_FLAG_END_STREAM 0x01

Definition at line 47 of file grpc_client.c.

◆ H2_FRAME_CONTINUATION

#define H2_FRAME_CONTINUATION 0x09

Definition at line 46 of file grpc_client.c.

◆ H2_FRAME_DATA

#define H2_FRAME_DATA 0x00

Definition at line 38 of file grpc_client.c.

◆ H2_FRAME_GOAWAY

#define H2_FRAME_GOAWAY 0x07

Definition at line 44 of file grpc_client.c.

◆ H2_FRAME_HEADERS

#define H2_FRAME_HEADERS 0x01

Definition at line 39 of file grpc_client.c.

◆ H2_FRAME_PING

#define H2_FRAME_PING 0x06

Definition at line 43 of file grpc_client.c.

◆ H2_FRAME_PUSH_PROMISE

#define H2_FRAME_PUSH_PROMISE 0x05

Definition at line 42 of file grpc_client.c.

◆ H2_FRAME_RST_STREAM

#define H2_FRAME_RST_STREAM 0x03

Definition at line 40 of file grpc_client.c.

◆ H2_FRAME_SETTINGS

#define H2_FRAME_SETTINGS 0x04

Definition at line 41 of file grpc_client.c.

◆ H2_FRAME_WINDOW_UPDATE

#define H2_FRAME_WINDOW_UPDATE 0x08

Definition at line 45 of file grpc_client.c.

Typedef Documentation

◆ grpc_client_frame

typedef struct grpc_client_frame grpc_client_frame

◆ grpc_client_header_cb

typedef void(* grpc_client_header_cb) (void *ctx, const char *name, const char *value)

Definition at line 394 of file grpc_client.c.

◆ grpc_client_headers_ctx

typedef struct grpc_client_headers_ctx grpc_client_headers_ctx

◆ grpc_client_hpack_entry

typedef struct grpc_client_hpack_entry grpc_client_hpack_entry

◆ grpc_client_msg

typedef struct grpc_client_msg grpc_client_msg

Function Documentation

◆ cwist_grpc_call_await_headers()

int cwist_grpc_call_await_headers ( cwist_grpc_call * call )

Block until response headers arrive or the stream ends.

Parameters

call The call.

Return values

0	Response headers received (the RPC is committed).
1	The stream ended before any response headers (retryable).
-1	Invalid call, error, or deadline.

Definition at line 1228 of file grpc_client.c.

Referenced by cwist_grpc_channel_call_start().

◆ cwist_grpc_call_cancel()

void cwist_grpc_call_cancel ( cwist_grpc_call * call )

Cancel a call: send RST_STREAM(CANCEL), mark it failed with CWIST_GRPC_CANCELLED, and end its stream.

Parameters

call	The call; NULL or an already-ended call is a no-op.

Definition at line 1308 of file grpc_client.c.

References cap, CWIST_GRPC_CANCELLED, and H2_FRAME_RST_STREAM.

Referenced by cwist_grpc_call_destroy(), and cwist_grpc_channel_call_cancel().

◆ cwist_grpc_call_committed()

int cwist_grpc_call_committed ( const cwist_grpc_call * call )

Whether response headers have committed the RPC (gRFC A6).

Returns: Nonzero if committed; 0 for a NULL call or not yet committed.

Definition at line 1241 of file grpc_client.c.

◆ cwist_grpc_call_destroy()

void cwist_grpc_call_destroy ( cwist_grpc_call * call )

Destroy a call: cancel it if still open, release it as the client's active call, and free all queued and buffered state.

Parameters

call	The call; NULL is a no-op.

Definition at line 1323 of file grpc_client.c.

References cap, cwist_free(), cwist_grpc_call_cancel(), and cwist_grpc_decoder_destroy().

Referenced by cwist_grpc_channel_call_destroy(), cwist_grpc_channel_call_start(), and cwist_grpc_client_close().

◆ cwist_grpc_call_finish()

cwist_grpc_status_t cwist_grpc_call_finish	(	cwist_grpc_call *	call,
		const char **	message
	)

Drain the call to completion and return its final status.

Parameters

call	The call.
message	When non-NULL, set to the status message text; the pointer is owned by the call and stays valid until cwist_grpc_call_destroy.

Returns: The final gRPC status code; CWIST_GRPC_INTERNAL for a NULL call.

Definition at line 1291 of file grpc_client.c.

References cap, and CWIST_GRPC_INTERNAL.

Referenced by cwist_grpc_channel_call_finish().

◆ cwist_grpc_call_recv()

int cwist_grpc_call_recv	(	cwist_grpc_call *	call,
		cwist_grpc_message *	out
	)

Receive the next response message of a call.

Parameters

call	The call.
out	Filled with the next message; out->data is owned by the call and stays valid until the next recv or cwist_grpc_call_destroy.

Return values

1	A message was returned.
0	The stream ended cleanly and no more messages will arrive.
-1	The call failed (see cwist_grpc_call_status).

Definition at line 1203 of file grpc_client.c.

References cap, cwist_grpc_message::compressed, cwist_free(), cwist_grpc_message::data, and cwist_grpc_message::len.

Referenced by cwist_grpc_channel_call_recv().

◆ cwist_grpc_call_refused()

int cwist_grpc_call_refused ( const cwist_grpc_call * call )

Whether the call failed before commit in a retryable way (gRFC A6 case 3: REFUSED_STREAM before headers, or GOAWAY below our stream id).

Returns: Nonzero if retryable; 0 otherwise (NULL, committed, or trailers seen).

Definition at line 1250 of file grpc_client.c.

Referenced by cwist_grpc_channel_call_start().

◆ cwist_grpc_call_retry_pushback_ms()

int cwist_grpc_call_retry_pushback_ms	(	const cwist_grpc_call *	call,
		int32_t *	out_ms
	)

Report the server-provided retry pushback delay, if any.

Parameters

call	The call.
out_ms	Set to the pushback delay in ms (negative = do not retry) when present.

Returns: Nonzero if the grpc-retry-pushback-ms trailer arrived; 0 otherwise.

Definition at line 1261 of file grpc_client.c.

References cap.

Referenced by cwist_grpc_channel_call_start().

◆ cwist_grpc_call_start()

cwist_grpc_call * cwist_grpc_call_start	(	cwist_grpc_client *	c,
		const char *	method,
		const void *	request,
		size_t	request_len,
		uint64_t	timeout_ms
	)

Start a unary call (no previous-attempt marker).

Parameters

c	Client; must be connected and have no active call.
method	gRPC method path (e.g. "/pkg.Service/Method").
request	Request message bytes; may be NULL when request_len is 0.
request_len	Request length in bytes.
timeout_ms	Per-call deadline in ms; 0 means no deadline.

Returns: The started call, or NULL on invalid arguments, a busy/dead client, or a transport error while sending.

See also: cwist_grpc_call_start_ex

Definition at line 1094 of file grpc_client.c.

References cap, and cwist_grpc_call_start_ex().

◆ cwist_grpc_call_start_ex()

cwist_grpc_call * cwist_grpc_call_start_ex	(	cwist_grpc_client *	c,
		const char *	method,
		const void *	request,
		size_t	request_len,
		uint64_t	timeout_ms,
		uint32_t	previous_attempts
	)

Start a unary call, with a gRFC A6 retry-attempt marker.

Sends HEADERS (:method POST, :scheme, :path, :authority, content-type, te) followed by the framed request message, then commits the call as the client's active call. Serialized by the client mutex: one active call per connection.

Parameters

previous_attempts Value for grpc-previous-rpc-attempts; 0 omits the header.

Returns: The started call, or NULL on invalid arguments, a busy/dead client, or a transport error while sending (state is cleaned up).

Definition at line 1112 of file grpc_client.c.

References cap, cwist_alloc(), cwist_free(), cwist_grpc_decoder_destroy(), cwist_grpc_decoder_init(), cwist_grpc_encode_message(), CWIST_GRPC_OK, H2_FLAG_END_HEADERS, and H2_FRAME_HEADERS.

Referenced by cwist_grpc_call_start(), and cwist_grpc_channel_call_start().

◆ cwist_grpc_call_status()

cwist_grpc_status_t cwist_grpc_call_status ( const cwist_grpc_call * call )

Current gRPC status code of a call.

Parameters

call The call.

Returns: The status code; CWIST_GRPC_INTERNAL for a NULL call.

Definition at line 1280 of file grpc_client.c.

References CWIST_GRPC_INTERNAL.

Referenced by cwist_grpc_channel_call_destroy(), and cwist_grpc_channel_call_start().

◆ cwist_grpc_client_close()

void cwist_grpc_client_close ( cwist_grpc_client * c )

Close the client: send GOAWAY, tear down TLS and the socket, free all state.

Parameters

c	Client to close; NULL is a no-op.

Definition at line 701 of file grpc_client.c.

References cap, cwist_free(), cwist_grpc_call_destroy(), H2_FRAME_GOAWAY, SSL_CTX_free, SSL_free, and SSL_shutdown.

Referenced by cwist_grpc_channel_close(), and cwist_grpc_client_connect().

◆ cwist_grpc_client_connect()

cwist_grpc_client * cwist_grpc_client_connect	(	const char *	host,
		uint16_t	port,
		const cwist_grpc_client_options *	options
	)

Connect to a gRPC server and complete the HTTP/2 handshake.

Parameters

host	Server hostname or address.
port	TCP port number.
options	Optional TLS/timeout/authority options; NULL for defaults (no TLS, 10 s connect timeout, authority "host:port").

Returns: Connected client on success; NULL on any failure (partially built state is cleaned up before returning).

Note: Performs TCP connect, optional TLS with ALPN "h2", sends the client preface and SETTINGS, and waits for the server SETTINGS and the ACK of our own SETTINGS.

Definition at line 624 of file grpc_client.c.

References cwist_grpc_client_options::authority, cap, cwist_grpc_client_options::connect_timeout_ms, cwist_alloc(), cwist_free(), cwist_grpc_client_close(), GRPC_CLIENT_DEFAULT_WINDOW, GRPC_CLIENT_HEADER_TABLE, H2_FLAG_ACK, H2_FRAME_GOAWAY, H2_FRAME_PING, H2_FRAME_SETTINGS, cwist_grpc_client_options::tls_server_name, cwist_grpc_client_options::use_tls, and cwist_grpc_client_options::verify_peer.

◆ cwist_grpc_client_dead()

int cwist_grpc_client_dead ( cwist_grpc_client * c )

Whether the client connection is unusable.

Returns: Nonzero if the client is NULL, the transport died, or GOAWAY arrived.

Definition at line 1271 of file grpc_client.c.

References cap.

Referenced by cwist_grpc_channel_get_state().

Macros

Typedefs

Functions

Detailed Description

Macro Definition Documentation

◆ _POSIX_C_SOURCE

◆ GRPC_CLIENT_DEFAULT_WINDOW

◆ GRPC_CLIENT_FRAME_HEADER

◆ GRPC_CLIENT_HEADER_TABLE

◆ GRPC_CLIENT_MAX_FRAME

◆ H2_FLAG_ACK

◆ H2_FLAG_END_HEADERS

◆ H2_FLAG_END_STREAM

◆ H2_FRAME_CONTINUATION

◆ H2_FRAME_DATA

◆ H2_FRAME_GOAWAY

◆ H2_FRAME_HEADERS

◆ H2_FRAME_PING

◆ H2_FRAME_PUSH_PROMISE

◆ H2_FRAME_RST_STREAM

◆ H2_FRAME_SETTINGS

◆ H2_FRAME_WINDOW_UPDATE

Typedef Documentation

◆ grpc_client_frame

◆ grpc_client_header_cb

◆ grpc_client_headers_ctx

◆ grpc_client_hpack_entry

◆ grpc_client_msg

Function Documentation

◆ cwist_grpc_call_await_headers()

◆ cwist_grpc_call_cancel()

◆ cwist_grpc_call_committed()

◆ cwist_grpc_call_destroy()

◆ cwist_grpc_call_finish()

◆ cwist_grpc_call_recv()

◆ cwist_grpc_call_refused()

◆ cwist_grpc_call_retry_pushback_ms()

◆ cwist_grpc_call_start()

◆ cwist_grpc_call_start_ex()

◆ cwist_grpc_call_status()

◆ cwist_grpc_client_close()

◆ cwist_grpc_client_connect()

◆ cwist_grpc_client_dead()
